Ethernet/IP Installers Course

EtherNet/IP networks require specialized wiring and cabling techniques to be robust and trouble-free.

This course will provide you with the knowledge and skills you need to run the communication cables, wire the connectors, test the cables, and setup basic equipment. You will also learn how to minimize the impact of EMC on the network. This Ethernet training uses real world examples and hands-on learning to provide you with the best training experience.

Upon completion of this Ethernet training, the student shall be able to:

• Add devices to an existing Ethernet/IP network
• Install and set up an Ethernet/IP network
• How to use both Implicit and Explicit messaging
• Understand how the network works generally
• Troubleshoot common and uncommon problems

Topics Covered:

• Introduction to EtherNet/IP
• Physical layers
• Cabling techniques
• Grounding and shielding
• Cable making and testing
• Setting IP addresses

Hands on Exercises

• Setting IP addresses
• Cable making and testing

Class Day Information:

• Attendees will receive: course notes, and a certificate of participation
• Class size is limited to a maximum of 8 people

Course Duration

This course is one day. The day includes 8 hours of instruction which includes two 15-minute breaks and one 30-minute lunch break.

Class Dates:

• Instructor led Online,(minimum of 3 to run this course)
• On-site classes are available upon request

Course Cost:

• $1,295 per person, plus applicable taxes.

Need to book a day, ask us. EtherNet training available on demand online or in person.

Need an introduction. Join the wait list for our EtherNet lunch and learn.

Check out the Canada Job Grant Program for your province. You can find links to your provincial information here.
